APPENDIX I: AM ERROR, STATE AND STATUS TABLES
OMM-0150_B • 5/20/2021 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 131 of 140
Appendix I: AM ERROR, STATE AND STATUS TABLES
Appendix I-1: AM Lockout Error Codes Table
Lockout errors are indicated by an ‘A’ displayed before the error code number.
“A” Lockout Error Codes
‘A’
CODE
ERROR NAME
INT.
#
DESCRIPTION
1
IGNIT_ERROR
1
Three unsuccessful ignition attempts in a row
2
GV Relay Error
2
Failure detected in the GV Relay
3
GV Relay not open error
3
Failure detected in the GV Relay
4
GV Relay not closing error
4
Failure detected in the GV Relay
5
Safety relay error
5
Failure detected in the Safety Relay
6
Safety relay open error
6
Failure detected in the Safety Relay
7
Safety relay closed error
7
Failure detected in the Safety Relay
11
Blocking too long error
11
Control had a blocking error for more than 20 hours in a row.
12
Fan error
12
Fan MF deviation for more than 60 sec
13
Ram error
13
Internal software error
14
Wrong eeprom signature
14
Contents of e2prom is not up-to-date
15
X ram error
15
Internal software error
16
E2prom error
16
No communication with E2prom
17
E2prom error safety C
17
Wrong safety parameters in e2prom
18
E2prom error Calibration table
18
Wrong calibration table parameters
19
State error
19
Internal software error
20
Rom error
20
Internal software error
21
Rom error C
21
Internal software error
22
Air sw not open
22
Air pressure switch not working
23
15MS XRL error
23
Internal software error
24
Air sw not closed
24
Air pressure switch not working
25
Max Temp. Error
25
The external overheat protection is activated
26
Stack error
26
Internal error
27
Flame out too late
27
Flame still present 10 sec. after closing the gas valve
28
Flame error 1
28
Flame is detected before ignition
29
20MS XRL error
29
Internal software error
30
41MS XRL error
30
Internal software error
31
Too many flame failures
31
Three times flame lost during one demand
32
Flow switch not closed
32
Flow switch not working / No flow
33
Flow switch not open
33
Flow switch not working / No flow
34
Flag byte integrity
34
Internal software error
35
AD Hi cpl.
35
Internal software error
36
AD Lo cpl.
36
Internal software error
37
Register error
37
Internal software error
