Watts Aerco ProtoNode FPC-N34 - Appendix C-8: MFC RWF55 Points

ProtoNode FPC-N34 & FPC-N35 User Manual
APPENDIX C: AERCO EQUIPMENT POINT MAPPINGS
OMM-0150_B • 5/20/2021 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 86 of 140
Appendix C-8: MFC RWF55 Points
Point Name
FPC-N34
FPC-N35
Modbus
Address
BACnet Data
Type
BACnet
Object Id
N2 Data
Type
N2 Point
Address
Lon Name
Lon SNVT Type
INPUT 1 X1
AI
1
AI
1
nvoX1_XXX
SNVT_count_inc_f
40001
INPUT 2 X2
AI
2
AI
2
nvoX2_XXX
SNVT_count_inc_f
40003
INPUT 3 X3
AI
3
AI
3
nvoX3_XXX
SNVT_count_inc_f
40005
CURRENT SETPOINT WR
AI
4
AI
4
nvoWR_XXX
SNVT_count_inc_f
40007
FIRST SETPOINT SP1
AV
5
AO
5
nvi/nvoSP1_XXX
SNVT_count_inc_f
40009
SECOND SETPOINT SP2
AV
6
AO
6
nvi/nvoSP2_XXX
SNVT_count_inc_f
40011
REMOTE OPERATING MODE
REM
AV
7
AO
7
nvi/nvoRem_XXX
SNVT_count_inc_f
41281
REMOTE MODE OFF ROFF
AV
8
AO
8
nvi/nvoRoff_XXX
SNVT_count_inc_f
41282
REMOTE ON HYSTERESIS
RHYS1
AV
9
AO
9
nvi/nvoRHYS1_XXX
SNVT_count_inc_f
41283
REMOTE OFF HYST
BOTTOM RHYS2
AV
10
AO
10
nvi/nvoRHYS2_XXX
SNVT_count_inc_f
41285
REMOTE OFF HYST TOP
RHYS3
AV
11
AO
11
nvi/nvoRHYS3_XXX
SNVT_count_inc_f
41287
REMOTE SETPOINT SPR
AV
12
AO
12
nvi/nvoSPr_XXX
SNVT_count_inc_f
41289
REMOTE BURNER OUTPUT
RK1
AV
13
AO
13
nvi/nvoRk1_XXX
SNVT_count_inc_f
41291
REMOTE K2 OUTPUT RK2
AV
14
AO
14
nvi/nvoRk2_XXX
SNVT_count_inc_f
41292
REMOTE K3 OUTPUT RK3
AV
15
AO
15
nvi/nvoRk3_XXX
SNVT_count_inc_f
41293
REMOTE K6 OUTPUT RK6
AV
16
AO
16
nvi/nvoRk6_XXX
SNVT_count_inc_f
41294
REMOTE STAGE MODE
RSTEP
AV
17
AO
17
nvi/nvoRstep_XXX
SNVT_count_inc_f
41295
REMOTE OUTPUT RY
AV
18
AO
18
nvi/nvoRy_XXX
SNVT_count_inc_f
41296
REM ON HYST COOLING
RHYS4
AV
19
AO
19
nvi/nvoRHYS4_XXX
SNVT_count_inc_f
41298
REM OFF HYST BTM
COOLING RHYS5
AV
20
AO
20
nvi/nvoRHYS5_XXX
SNVT_count_inc_f
41300
REM OFF HYST TOP
COOLING RHYS6
AV
21
AO
21
nvi/nvoRHYS6_XXX
SNVT_count_inc_f
41302
INPUT 3 UNFILTERED TEMP
AI
22
AI
22
nvoIn3_UnflTmp_XXX
SNVT_count_inc_f
44150
