APPENDIX C: AERCO EQUIPMENT POINT MAPPINGS
OMM-0150_B • 5/20/2021 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 78 of 140
Appendix C-4: Modulex Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus TCP/IP and LonWorks
Name
Point Name
BACnet
Object
Type
BACnet
Object
ID
N2
Data
Type
N2 Point
Address
Lon Name
Lon SNVT
Modbus
Address
Modulation Level In
boilerload_XXX
AV
5
ADF
5
nvoMlxLoad_XXX
SNVT_count_inc
41201
Flow Sensor Temp
localsuptemp_XXX
AV
6
ADF
6
nvoMlxSupTmp_XXX
SNVT_count_inc
41003
Display Code
dispcode_XXX
AV
7
ADF
7
nvoMlxDispCd_XXX
SNVT_count_inc
30001
Error Code
errcode_XXX
AV
8
ADF
8
nvoMlxErrCod_XXX
SNVT_count_f
40001
Unit Status
unitstat_XXX
AV
9
ADF
9
nvoMlxStat_XXX
SNVT_count_inc
30002
Return Flow Temp
returntemp_XXX
AV
10
ADF
10
nvoMlxRetTmp_XXX
SNVT_count_inc
41004
Appendix C-5: ECS/SP Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus TCP/IP and LonWorks
Appendix C-5: ECS/SP Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus TCP/IP and LonWorks
Name
Point Name
BACnet
Object
Type
BACnet
Object
ID
N2
Data
Type
N2 Point
Address
Lon Name
Lon SNVT
Modbus
Address
Control Output Signal
boilerstate_XXX
AV
1
ADF
1
nvoEcsState_XXX
SNVT_count_inc
30004
Target Setpoint
effectsetpt_XXX
AV
2
ADF
2
nvoEcsSetpt_XXX
SNVT_count_inc
30006
Remote Setpoint
setpt_XXX
AV
3
ADF
3
nviEcsSPRq_XXX
SNVT_count_inc
40027
Outlet Temp
localsuptemp_XXX
AV
4
ADF
4
nvoEcsSupTmp_XXX
SNVT_count_inc
30002
Fbk Sensor Temp
localrettemp_XXX
AV
5
ADF
5
nvoEcsRetTmp_XXX
SNVT_count_inc
30290
Over Temp Alarm
unitstat_XXX
AV
6
ADF
6
nvoEcsStat_XXX
SNVT_count_inc
30075
Flow Rate/Mixed
Temp
flowrate_XXX
AV
7
ADF
7
nvoEcsFlow_XXX
SNVT_count_inc
30291
