DBW 2010 / 2016 2 General Description
203
Fig. 202 DBW 2010 heaters with sensor technology
1Burner head
2 Ignition spark generator
3 Coolant, outlet
4 Temperature sensor *
5 Thermal fuse *
6 Temperature limiter *
7Heat exchanger
8Exhaust outlet
9 Control unit
* for components installed in accordance with the
heater variant
