2 General Description DBW 2010 / 2016
206
2.4 Heat exchanger
The heat generated in the heat exchanger by combustion is
transferred to the coolant circuit.
2.5 Combustion chamber
The fuel-air mixture is distributed in the combustion chamber
and burned there. The heat exchanger is heated in the proc-
ess.
2.6 Control unit
The control unit is the central component and ensures the
operating sequence and the monitoring of combustion oper-
ation.
Fig. 208 Heat exchanger
Fig. 209 Combustion chamber
DBW
2010 / 2016
(may differ, according to
variant)
DBW 2010 / 2016
Fig. 210 1553 control unit
Fig. 211 1563/1564 control unit for heaters with sensor
technology
