DBW 2010 / 2016
905
Fig. 904 Electrical connection
Item
D
es
c
riptio
n
Comment
A1
Heate
r
A2
Contr
ol
un
it
SG
1553
B
Plug co
n
nector, 6-pin
B5
The
r
mostat
for nozzle holder pre-h
eating unit
F1
10
A fuse
Flat fuse SAE J 1284
F2
20
A fuse
Flat fuse SAE J 1284
F3
16
A (12
V); 8
A (24
V) fuse
Flat fuse SAE J 1284
G
Battery
H1 Lamp
Operation
indicator
K6
Relay
for nozzle holder pre-h
eating unit
R2
Heating cartridge
for nozzle holder pre-h
eating unit
S1 Switch
ON/OFF
S2 Switch
On
water
valve
W2 Wiring
harness
X1
Plug connector, 4-pin
