Webasto SVS300 User Manual

SVS-200 Installation, Operation and Maintenance
IMPORTANT INFORMATION – SAVE THESE INSTRUCTIONS
20153-W-03-01 7 Webasto Charging Systems, Inc.
4.2 Wiring
4.2.1 General Guidelines
 Check utility configuration tag on SVS-300 to make sure that rated input voltage matches
local utility voltage. See Table 4-1 for details.
 See Table 4-1 for Input/Output parameters.
4.2.2 Ground Wire
 Green or green with a yellow stripe and attached to the compression lug provided.
4.2.3 Charging Cables / Cable Management System
 To avoid shock hazard, only install cables approved by PosiCharge™ for indoor use.
DANGER
CABLES CARRY HIGH POWER/CURRENT
Damaged Cables and/or connectors can be a serious safety hazard.
Cables must be secured with an Approved Cable Management System.
Cables are to be kept off the floor.
Failure to use a Cable Management System may invalidate Product
Warranty.
4.2.4 Chassis Ground
 See Table 4-1 for wiring size (AWG) and additional information.
 Use THHN or similar type, 600V, 90° C, suitable for conduit use.
 Use copper conductors only.
 Minimum ground wire size is listed. Refer to local electrical codes for reference.
4.2.5 Grounding
 SVS-300 must be connected to an equipment-grounding conductor routed with the circuit
conductors. Connections must comply with all local codes and ordinances.
 The SVS-300 must be grounded in accordance with the Facilities Utility grounding method.
 See Table 4-1 for minimum ground wire size.
4.2.6 Hardware
Manufacturer does not supply all external mounting hardware. User-supplied hardware may be
needed to complete the installation.
