Webasto SVS300 User Manual

SVS-200 Installation, Operation and Maintenance
IMPORTANT INFORMATION – SAVE THESE INSTRUCTIONS
20153-W-03-01 43 Webasto Charging Systems, Inc.
Table 6- 1 Fault Codes
Code
Fault Messages
Meaning
100
OS System Failure
Power on self test/OS failure
101
Pilot Int. Failure
Pilot interrupts stopped
occurring
102
ADC Failure
A to D Converter failure
103
Invalid Pilot
Battery connected with invalid
pilot circuit
104
Chrg Vdc Port Low
Battery voltage too low for
charger
105
Chrg Vdc Port High
Battery voltage too high for
charger
106
BMID Vbat Too Low
Battery voltage too low for
BMID
107
BMID Vbat Too High
Battery voltage too high for
BMID
108
Vbat Mismatch
BMID and terminal voltages
don’t match
109
Tbat Too High
Battery temp too high
110
Batt Over-discharge
Battery excessively discharged
111
BMID Comm Fail
BMID link lost after charge
started
113
BMID Param Mismatch
BMID data doesn’t match
battery parameters
114
Powerstage Too Hot
Powerstage temperature over
limit
115
Powerstage Shutdown
Powerstage shutdown
autonomously
117
BMID Failure
BMID reporting a critical failure
118
Control Bd Supply
Control board logic supply
failure
120
Current Too Low
Powerstage not producing
desired current
121
ADC Ref Invalid
A to D Converter inputs invalid
122
HW Overvolt
Overvoltage detected in
hardware
123
HW Overcurrent
Overcurrent detected in
hardware
