Figure 5- 24 Date and Time setting menus
5.10.14 Charge Time Control
The Charge Time Control entry screens (see Figure 5- 25) allow the user to review and edit the
scheduled charge delays for the charger.
In each menu, press <enter> to enable editing (the value will start to flash) and use the <up> and
<down> arrows to adjust the value. Press <enter> again to accept new value, or <clear> to
cancel the editing and retain the old value.
Figure 5- 25 Charger Time Control Menu
Auto Charge Restart – Displays and edits the number of hours before an automatic charge restart
event. This event will take place if a vehicle is left connected to the charger for the time entered
after its charge event has completed.
Month
11
Set Date and Time
CLEAR
ENTER
Hours
13
ENTER
Minutes
15
ENTER
Day
24
ENTER
Year
2001
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
Press ENTER and
use the UP and
DOWN arrow
buttons to set the
parameter to the
appropriate value.
Press ENTER again
to accept the
selection made.
Press CLEAR to
retain the original
value
CLEAR
Charger Configuration
ENTER
Charge Time
Control
Auto Charge Restart
6 Hours
ENTER
ENTER
CLEAR
Charger Configuration
Press ENTER and use the UP and
DOWN arrow buttons to set the
parameter to the appropriate value.
Press ENTER again to accept the
selection made.
Press CLEAR to retain the original value
CLEAR
