Webasto SVS300 User Manual

SVS-200 Installation, Operation and Maintenance
IMPORTANT INFORMATION – SAVE THESE INSTRUCTIONS
20153-W-03-01 11 Webasto Charging Systems, Inc.
Utility power lines to SVS-300 must be provided from an appropriately rated utility distribution
panel. The utility distribution panel must include a "branch" rated circuit breaker (CB). The CB
may also be the "line disconnect" device.
Utility power must be 50/60Hz, 3 phase, 3 wire plus ground. There must be one wire for each
phase plus one earth ground. See Table 4-1 for information on input current, utility requirement,
and cable sizes. All phase wires must be rated for the full input AC current as listed.
Table 4-1 Utility and Wiring Information
Configuration
30kW
Input voltages
440 VAC ± 10%
Input AC Current at rated load (Amps)
46 @ 440V
Input Frequency (Hz)
50 / 60
Number of input Phases (Excluding Ground)
3
Maximum Circuit Breaker Rating (Amps)
58
Minimum Disconnect Switch Voltage Rating (VAC)
600
Minimum Inrush Current Capacity (Amps)
300A, 2 cycle start-up load
THD Max
35%
Minimum Input Conductor Size (mm
2
)
16mm
2
Minimum Grounding Conductor Size (mm
2
)
16mm
2
Minimum Input Wire Terminal Torque (in-lb)
N/A
Minimum Ground Wire Terminal Torque (in-lb)
4-5 Nm
Reference National Electrical Code. ANSI/NFPA 70.1999
Table 4-2 Output Characteristics for SVS-300
Configuration
Single Output
Cable
Max Output Power (kW)
30
Max Output DC Range (Volts)
16-130
Max Output DC Current (Amps)
320
Minimum Output Wire Size (DC BUS +, mm
2
)
95mm
2
Minimum Output Wire Size (DC BUS -, mm
2
)
95mm
2
