5.10.10 Air Circulation Control
NOTE: This section is only applicable if a Air Pump System has been installed and
connected to the charger.
The Air Circulation Control menus allow the user to set the Air Circulation control parameters.
From this menu, the charger Air Circulation Control can be Enable.
From the “Air Circulation Control” screen Press <enter> and then Press <enter> again and the
status (Enable or Disable) will flash. Press <up> or <down> to toggle between ON and OFF.
Press <enter> again to accept your selection. Press <clear> to exit.
Figure 5- 21 Air Circulation Control Setup
5.10.11 Watering System
Allows the user to configure the charger to use any one of several pre-determined watering
systems or to set up a custom watering profile that allows the user to program the duration of the
watering period. The watering system, when active, is always set to turn on two hours into the
EQ.
From the “Watering System Configuration” screen, press <enter> to display the Water System
Configuration status. Press <enter> again to enable editing. Use the <up> and <down> buttons
to toggle between “ON” and “OFF” and press <enter> to accept edits. Use the <select> button to
cycle through the remaining screens. To set Watering System Type Press <enter> again to
enable editing. Use the <up> and <down> buttons to toggle between the different types of
Watering Systems and press <enter> to accept edits.
If you have selected the Watering System Type “Custom Mode”, you will be able to edit the “ON
Time” and you will be able to perform a watering system test. In “Custom Mode” press <enter>
again to enable editing of the “Valve Turn On Time”. Use the <up> and <down> buttons to set
ON time “00:00 MIN” and press <enter> to accept edits. Once editing is complete, use the <clear>
button to return to the “Water System Type” screen. From this screen, press <select> to enter the
”Water System Test” screen. From this screen press <enter> to run the water test. There will be
a 30 second count down and then watering will begin. Press the <stop> button to end the test.
Press the <clear> button to exit.
Air Circulation
Enable
Air Circulation
Disable
Air Circulation
Control
CLEAR
ENTER
CLEAR
Charger Configuration
CLEAR
Verify Air Pump
Connection
ENTER
CLEAR
ENTER
