WEIHONG Ncstudio V15 User Manual

上海维宏电子科技股份有限公司
SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD.
9 / 116
3. Configure the devices based on your demands:
o To add a controller/terminal board, right-click on BusO and select Add
controller and select the target controller/terminal board.
o To replace a controller/terminal board, right-click on the controller/terminal
board to be replaced and click Replace. Select the target controller/terminal
board in the displayed list.
o To delete a controller/terminal board, right-click on the controller/terminal
board to be deleted and click Delete.
o To move a controller/terminal board, click the controller/terminal board to be
moved and click Up/Down.
4. Save the change by clicking or .
Follow the steps below to configure port mapping:
1. In the left column, click the Configuration tab. Go to NcStudio > Hardware
Connection and Configuration > Port Mapping.
2. Double-click Port Mapping to open the Port Mapping window to the right.
3. In the port list:
o To show only a certain type of ports, click the category on the left, such as
Lubricate.
o To modify the physical address of a logical address, double-click the
corresponding physical address box and select the target controller and port.
o To show/hide the logical addresses, right-click on the Enter/Output list and
select Display logical address/Hide logical address.
o To delete a port mapping, right-click on the Enter/Output list and select
Delete port mapping.
o To delete invalid port mapping, right-click on the Enter/Output list and select
Delete invalid port mapping.
3.2.4 Port Protection
When the software is closed, the protected ports will be automatically closed, opened,
following the status of the specified port, or reversed based on their port protection type.
There are several types of port protection:
 Open: The port will be automatically opened when the software is closed.
 Closure: The port will be automatically closed when the software is closed.
 Follow: The protected port status will be turned the same with that of the port
specified in the Follow port column.
 Reverse: The protected port status will be turned the opposite to that of the port
specified in the Follow port column.
Follow the steps below to set port protection:
1. In the left Configuration list, double-click Port Protect to open the Port Protect
window to the right:
