Field replaceable units
If a Version 1 (serial number less than 200705000) is sent in for updates or repair to the
main printed circuit board, it is necessary to upgrade the keypad and front housing/bezel
assembly. The Spot Vital Signs is then referred to and functions as a Version 2. See
Table 1 on page 1 for the specific version differences.
The following lists identify the available FRUs for Spot Vital Signs. To order an FRU,
contact Welch Allyn Technical Support.
Parts listed below are used in both Version 1 and Version 2 unless otherwise indicated.
Table 17. Repair Replacement Table (Version 1 only)
Faulty Part Replacement Part(s)
Main PCB assembly 421267-501
(Print option)
Main PCB assembly 403290 (Pressure Preset option)
Front Housing (Version 2) 403300
Switch Array (Version 2) 706213
Directions for Use (English) 706272
LCD 421020-501 LCD 706062
Switch Array (Version 1) Switch Array (Version 1) 703430
Front Housing (Version 1) 421049-502 Front Housing (Version 1) 421049-502
Table 18. Spot Vital Signs Repair Parts List
Description Part Number Source
Probe Assembly, Lathg Conn. Oral-9Ft 02678-100 Welch Allyn
Probe Assembly, Lathg Conn, Rectal-9Ft 02679-100 Welch Allyn
M031 Probe Cover Clear - 1K 05031-101 Welch Allyn
Cable Tie Mount 113P463
Cable Tie, 6 inch 113P464
Switch Array, Spot, Epoxy Coated, Version 1 703430 Welch Allyn
Grommet, Ribbed, Shock Isolation 421019
Assembly, Spot Pump Repair 421023-501 Welch Allyn
Flex Cable, Main to Display 421030 Welch Allyn
S/N Tracking Label, Version 1 402427 Welch Allyn
S/N Tracking Label, Version 2 403430
Screw, 4-20 x .31 Plastite PH Torx 421037
Lockwasher, 5/16 Internal Tooth 421039
