Replacing Consumable 67
IE
IE
Replacement Procedure
Use the following procedure to replace the print
cartridge and to clean inside the printer.
1. If paper is loaded in the bypass tray, remove
the paper and close the bypass tray cover.
Important
• When closing the bypass tray cover, be careful not to
get your fingers caught between (the left or right edge
of) the cover and the printer.
2. Pull the front cover release levers ("A")
towards you and open the front cover.
3. Open the top cover.
4. Hold the print cartridge by the handles as
shown in the figure and remove the print
cartridge from the printer.
Note
• When removing the print cartridge, slide the cartridge
towards you.
Important
• Be careful not to dirty your hands or clothes with toner. If
toner gets on your hands or clothes, wash it off
immediately.
5. Remove the new print cartridge out of its
packaging.
Important
• Do not touch the photoconductor (drum) protection
shutter and photoconductor (drum) of the print cartridge.
6. Hold the print cartridge horizontally. Gently
shake the cartridge ten times or so in the
direction shown in the figure to even out the
toner inside.
Important
• Make sure to hold the cartridge by the handles at both
ends as shown in the figure and slowly shake it.
photoconductor (drum)
photoconductor (drum)
protection shutter
To Next Page
