Xerox Phaser 3150 Service Manual

Parts List
Service Manual 8-11
Fuser Assembly Parts List 8.4
No. Part Name and (part description) Qty Part number Remark
0 ELA HOU-FUSER 110V 1 126N00229 110V
0 ELA HOU-FUSER 220V 1 126N00230 220V
1 COVER-FUSER R2 1
2 HOLDER-PLATE CLAW R2 4
3 SPRING ETC-CLAW 4
4 PMO-ROLLER_EXIT 2
5 SPRING ETC-FUSER EXIT 2
6 THERMOSTAT-150 1 130N01265
7 PMO-GEAR_EXIT_DRV16 1
8 GEAR-IDLE 23 1
9 RING-E 1
10 GEAR-RDCN 25/15 1
11 ROLLER-HEATER 1
12 ELECTRODE-LFET R2 1
13 THERMISTOR-NTC 1 130N01266
14 ELECTRODE-RIGHT R2 1
15 CBF HARNESS-FUSER 110V 1 WHITE
CBF HARNESS-FUSER 220V 1 BLACK
16 BUSH-HR R_R2 1
17 LABEL(P)-CAUTION, HOT_FUSER 1
18 RMO-RUBBER_EXIT 2
19 ROLLER-M-EXIT F/UP 1
20 ROLLER-PRESSURE 1
21 BEARING-PRESSURE/R 2
22 SPRING-CS 2
23 PMO-BUSHING TX 3
24 HOLDER-ACTUATOR 1
25 PMO-ACTUATOR EXIT R2 1
26 FRAME-FUSER R2 1
27 GUIDE-INPUT R2 1
28 SPRING-TS 1
29 NUT-HEXAGON 5
30 BUSH-HR L_R2 1
31 PLATE-P-CLAW 4
32 GEAR-FUSER R2 1
33 LAMP-HALOGEN 110V 1 122N00231 110V
LAMP-HALOGEN 220V 1 122N00229 220V
34 LABEL(R)-HV FUSER 1
35 SCREW-TAPTIEE 1
36 SCREW-ASS'Y MACH 6
37 SCREW-TAPTIEE 6
38 BRUSH-ANTISTAIC 1
