Xerox Phaser 3150 Service Manual

Parts List
8-16
Tray 3 (SCF - Optional Cassette) Assembly Parts List 8.7
No. Part Name and (part description) Qty Part number Remark
0 ELA HOU-SCF H2 1 097N01439
1 COVER-M-FRONT SCF H2 1
1-1 SPRING-ES 2
1-2 ROLLER-IDLE FEED 2
2 COVER-M-LEFT SCF H2 1
3 COVER-M-RIGHT SCF H2 1
4 COVER-M-REAR SCF H2 1
5 FRAME-M-SCF 1
6 HOUSING-M-PICKUP _R2 1
7 HOUSING-M-PICKUP2 _R2 1
8 SPONGE-ROLLER PICK_UP 1
9 SHAFT-P-CORE 2
10 STOPPER-M-PICK_UP_R2 2
11 BUSHING-PICK_UP L 1
12 BUSHING-PICK_UP R 1
13 SHAFT-P-PICK_UP 1
14 PMO-IDLE PICK_UP 2
15 ROLLER-FEED 1
16 PMO-BUSHING FEED 2
17 PMO-GEAR PICK_UP A 1
18 PMO-GEAR PICK_UP B 1
19 SPRING-CS 1
20 RING-CS 1
21 CAM-M-PICK_UP 1
22 SHAFT-FEED 1
23 GEAR-FEED 2 1
24 SPRING-TS 1
25 PCB-SENSOR 1
26 PBASUB-SCF 1
27 CBF HARNESS-SCF GND 2
28 CBF HARNESS-SCF 1
29 COVER-M-SIMM R2 1
30 SHEET-COVER SENSOR 1
31 PMO-ACTUATOR EMPTY 1
32 IPR-GND TOP 1
33 SOLENOID-HB (MANUAL) 1
34 PMO-LOCKER CST 2
35 FOOT-BACK 2
36 FOOT-FRONT 2
37 SCREW-ASS'Y TAPT 1
38 SCREW-TAPTITE 4
39 ELAHOU-MOTOR SCF 1
39-1 BRKT-P-MOTOR SCF 1
39-2 BRKT-P-GEAR SCF 1
39-3 BRKT-M-FEED SCF 1
39-4 GEAR 61/47 IDLE 1
39-5 GEAR 59 IDLE 1
