Xinje DS2-22P3-AS User Manual

77
Changeable
signal
distribution
/S-ON, /P-CON, /P-OT, /N-OT, /ALM-RST, /PCL, /NCL,
/SPD-D, /SPD-A, /SPD-B, /C-SEL, /ZCLAMP, /CLR, /G-SEL,
/CHGSTP
Output
signal
External
output
3
Changeable
signal
distribution
/COIN, /V-CMP, /TGON, /S-RDY, /CLT, /VLT, /BK, /WARN,
/NEAR, /ALM, /Z
Built
-
in function
Dynamic brake (DB)
No
Regeneration
DS2-20P□-AS/AS6, DS2-20P4-BS/BS6: no internal
regenerative resistor
DS2-20P7-BSW/BSW6, DS2-21P5-AS/AS6, DS2-21P5-AS2,
DS2-22P3-AS/AS6, DS2-4□P□-AS/AS6: with internal
regenerative resistor
Regenerative frequency
(s/minute discharging)
DS2-2□P□-AS/AS6, DS2-21P5-AS2: 2.5 s/min
DS2-41P5-AS/AS6: 0.6 s/min
DS2-43P0-AS/AS6: 0.8s/min
DS2-20P7-BSW/BSW6: 1.6 s/min
Over range（OT）protection
For P-OT, N-OT action, deceleration stop or inertia stop
Electronic gear
0.01≤ B/A≤100
Protection
Program error, parameter error, overvoltage, undervoltage,
regeneration error, overtemperature, overcurrent, overspeed,
analog input error, position offset overflow, output shorting,
current error, encoder cut, encoder error, overload, power off
when running, write parameter error…
LED display
Charge, power supply, 7-segment LED ×5 (built-in digital
operate)
communication
COM1
Connector
RS232, connect to PC
Serial
parameter
Baud rate 19200; data bit 8; stop bit 1;
communication protocol: ModubsRTU slave;
Modbus station No.1
Function
Debug online
COM2
Connector
RS485, connect to PLC, HMI, PC and other
devices
Serial
parameter
Serial parameter can be set; communication
protocol: Modbus RTU slave; Modbus station No.
can be set
Function
State display, user constant setting, monitor
display, alarm display, alarm display, special
control, online debug
7-2-3．Servo drive dimensions
 DS2-20P□-AS/AS6, DS2-20P4-BS/BS6 (unit: mm)
