Xinje DS2-22P3-AS User Manual

80
8 Alarm Information
Alarm
Code
Description
Reason
Solution
E-001
Program damage
program self-test failed
Re-download the program or
contact Xinje or an authorized
distributor
E-002
Parameter damage
Parameter self-test
failed
Restart the drive to reset the
parameters. If it occurs for many
times please contact Xinje or an
authorized distributor
E-003
Bus over-voltage
Power grid is over
votage or need a
regenerative resistor;
the regenerative resistor
damage or its value is
too large
Check the power grid; connect
and check the regenerative resistor
E-004
Bus under
voltage
Power grid is under
votage
Check the power grid
E-005
Regenerative
resistor error
Regenerative resistor is
ineffective
Check the connection of
regenerative resistor
E-006
Module over
temperature
Run with large load for
long time
Reduce the load, and enhance the
cooling system, or check if the fan
is revolving when motor is ON;
cool down the ambient
temperature
E-007
Over current
UVW of drive is short
circiut or the motor is
error
Replace the damaged motor;
check the UVW wiring.
E-008
Over speed
Motor speed is too fast,
motor UVW
connection is error
Check if there is other device that
make motor revolve too fast;
check the UVW wiring.
E-009
Analog input error
Input voltage error
when 2-channe analog
zero calibrating
Input correct voltage when zero
calibration for analog
E-010
Position offset too
large
The difference between
set position and actual
position exceeds the
limit value
Check if the motor stalled,
decrease the set position speed,
increase offset pulse limit value
P5-05
E-011
Motor UVW is
short circiut
External is short circuit
when fist self-test
Check the UVW wiring of motor,
or replace the damaged motor
E-012
Motor UVW
current error
Current collection
circuit error
Check the UVW wiring of motor,
or replace the damaged drive
E-013
Encoder UVW
wire break
Encoder wiring error,
encoder broken,
encoder is not
connected
Check the wiring of encoder, and
re-connect the encoder after
power-off, or replace the damaged
encoder
E-014
Encoder ABZ
Encoder wiring error,
Check the wiring of encoder, and
