Yamaha F4B - Intake Silencer and Carburetor Service

6-10
Intake silencer
0
1
2
3
4
5
6
7
8
9
10
A
Intake silencer
No. Part name Q’ty Remarks
1Hose 1
2Hose 1
3Bolt 1 M6  35 mm
4 Washer 1
5 Collar 1
6 Throttle cam 1
7Lever 1
8 Holder 1
9 Clamp 3
10 Gasket 1 
11 Throttle link rod 1
12 Intake manifold bolt 2 M6  25 mm
13 Intake manifold 1
14 Gasket 2 
15 Spacer 1
16 Cap 1
17 Hose 1
21
20
20
17
16
11
10
2
9
3
4
5
6
7
8
14
15
14
13
12
18
9
9
21
22
19
23
1
12 N·m (1.2 kgf·m, 8.9 ft·lb)
Fuel tank / Intake silencer
