2-7
TECH
FEA
Technical features and descri
ption
Lighting coil (optional f
or European market)
The F4B
, F5A, F6C can be equipped wit
h a flywheel magnet, lighting
coil, and Rectifier Regulator
,
av
ailable as o
ptional accessories, to en
able ba
tter
y charging.
The electrical current generating cap
acity is 6A when the engine speed is at 6000 r/min.
a
Lighting coil
b
Rectifier Regulator
c
Fuse
d
Batter
y
e
Switch
f
Electrical component
a
b
c
d
e
f
35
37
