Yamaha HTR-6030 Service Manual

RX-V361/HTR-6030/DSP-AX361
20
RX-V361/HTR-6030/
DSP-AX361
■ SELF DIAGNOSIS FUNCTION (DIAG)／自己診断機能（ダイアグ）
This unit has self diagnosis functions that are intended for
inspection, measurement and location of faulty point.
There are 18 DIAG menu items, each of which has sub-
menu items.
Listed in the table below are menu items and sub-menu
items.
Note that not all menu items listed will apply to the models
covered in this service manual.
本機には、検査、測定、不良個所の発見を目的にした自己
診断機能（ダイアグ）があります。
ダイアグメニューは18個あり、そのそれぞれにサブメ
ニューがあります。
下表はダイアグメニュー一覧です。
下表の全ダイアグメニュー項目が、このサービスマニュア
ル記載のモデルに適用されるとは限りません。
No. DIAG menu Sub-menu
1
2
3
4
5
6
7
8
9
10
11
12
13
BYPASS
AUDIO CHECK
SPEAKERS SET
6CH-INPUT
MIC CHECK
FL/OSD CHECK
TEST TONE
FACTORY PRESET
AD DATA CHECK
XM STATUS
(U, C models)
DOCK
USB
(Not applied to these models.)
DAB
(Not applied to these models.)
ANALOG BYPASS
DSP BYPASS
AUDIO CHECK
FRNT : SML 0dB
CENTER : NONE
LFE/B : FRNT
TONE : MAX
TONE : MIN
6ch INPUT 6-ohm
6ch INPUT 8-ohm
LIM : , PLDET : , THM :
MIC CHECK
VFD CHECK
VFD DISP OFF
VFD DISP ALL
VFD DIMMER
CHECK PATTERN
TEST ALL
TEST FRNT L
TEST CENTER
TEST FRNT R
TEST SURR R
TEST SURR L
TEST LFE
PRESET INHI
PRESET RSRV
PD : , PV :
TH : , PL :
PI : , DE :
K0 : , K1 :
1k -1dB/44
1k -61dB/44
Mute/44
XM Tone/44
ISO Tone/44
1k -1dB/32
1k -61dB/32
Mute/32
XM Tone/32
ISO Tone/32
Bus Power : OFF
DOCK :
DOCK ignore
USB 1
USB 2
DAB 1
DAB 2
DAB 3

Yamaha HTR-6030 Specifications

General

Channels	5.1
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
FM/AM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	100 dB
Total Harmonic Distortion	0.9%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Audio D/A Converter	192kHz/24-bit
Surround Sound Effects	Yes
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	14
Tuner Bands	FM/AM
Preset Station Qty	40
Frequency Response	10 Hz - 100 kHz
Power Output	100 W per channel
Built-in Decoders	Dolby Digital, DTS
Connector Type	Headphones, Composite video/audio input/output
Video Inputs/Outputs	composite video / audio input, composite video / audio output, HDMI input, HDMI output
Audio Inputs/Outputs	2 Optical digital inputs, 1 Coaxial digital input
