Yamaha HTR-6030 Service Manual

2
ABCDEFGH I J
1
3
4
5
7
RX-V361/HTR-6030/DSP-AX361
6
92
• OVERALL ASS’Y
J model
R, L models
T, K, A, B, G, E models
103
103
160
201
201-1
202
156
157
157
157
7
(5)
6
164
160
160
160
160
160
(3)
6
12
15
16
17
22
23
101
103
109
120
120
121
151
152
167
167
167
167
168
168
170
170
171
171
172
160
200
200-1
U, C, R, T, L, J models
202
203
K, A, B, G, E models
Front Panel Unit
AMP Unit
163
163
163
163
163
(3)
5
(2)
5

Yamaha HTR-6030 Specifications

General

Channels	5.1
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
FM/AM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	100 dB
Total Harmonic Distortion	0.9%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Audio D/A Converter	192kHz/24-bit
Surround Sound Effects	Yes
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	14
Tuner Bands	FM/AM
Preset Station Qty	40
Frequency Response	10 Hz - 100 kHz
Power Output	100 W per channel
Built-in Decoders	Dolby Digital, DTS
Connector Type	Headphones, Composite video/audio input/output
Video Inputs/Outputs	composite video / audio input, composite video / audio output, HDMI input, HDMI output
Audio Inputs/Outputs	2 Optical digital inputs, 1 Coaxial digital input
