Yamaha HTR-6030 Service Manual

RX-V361/HTR-6030/DSP-AX361
33
RX-V361/HTR-6030/
DSP-AX361
10.1k - 1dB/44
1 kHz, -1 dB / 44.1 kHz
The test tone (1 kHz, -1 dB / 44.1 kHz) is output.
1 kHz, -61 dB / 44.1 kHz
The test tone (1 kHz, -61 dB / 44.1 kHz) is output.
Mute / 44.1 kHz
No signal is output.
XM tone / 44.1 kHz
The XM tone / 44.1 kHz is output.
ISO tone / 44.1 kHz
The ISO tone /44.1 kHz is output.
1 kHz, -1 dB / 32.0 kHz
The test tone (1 kHz, -1 dB / 32.0 kHz) is output.
1 kHz, -61 dB / 32.0 kHz
The test tone (1 kHz, -61 dB / 32.0 kHz) is output.
Mute / 32.0 kHz
No signal is output.
XM tone / 32.0 kHz
The XM tone / 32.0 kHz is output.
ISO tone / 32.0 kHz
The ISO tone / 32.0 kHz is output.
XM bus power: OFF
The power of XM module is turned off.
10.MUTE /44
10.XM TONE /44
10.ISO TONE/44
10.1k - 1dB/32
10.1k -61dB/32
10.MUTE /32
10.XM TONE /32
10.ISO TONE/32
10.BUS PWR:OFF
10. XMSTATUS（U、Cmodels）10. XM STATUS (U, C models)
The output check of XM radio antenna module is ex-
ecuted.
10.1k -61dB/44
11.DOCK:NG NNN 11.DOCK IGNORE
11. DOCK
このモデルには適用されません。
11. DOCK
Not applied to these models.
12. USBCHECK
このモデルには適用されません。
12. USB CHECK
Not applied to these models.
12.USB 1 12.USB 2
