Yamaha HTR-6030 Service Manual

ABCDEFGH I J
1
2
3
4
5
6
7
RX-V361/HTR-6030/DSP-AX361
67
IC161
IC168
IC164
IC163
IC162
IC169
MAIN (1) P.C.B.
(Side B)
1
1
1
1
4
8
5
4
85
4
4
5
8
5
8
1
100
50
51
30 31
81 80
18
916
B, G, E models
• Semiconductor Location
- D103 C5
D104 F5
D107 G5
D161 D3
D162 D3
D163 E3
IC161 C3
IC162 B3
IC163 B3
IC164 B2
IC168 F3
IC169 B4
Q101 B5
Q102 B5
Q103 B5
Q104 B5
Q105 B5
Ref no. Location Ref no. Location
Q106 B4
Q107 B4
Q108 B4
Q121 H3
Q122 G3
Q123 F4
Q125 G3
Q126 F4
Q127 G3
Q129 H3
Q130 G3
Q131 F4
Q132 H3
Q133 H3
Q161 G3
Q162 G3
Q163 F3

Yamaha HTR-6030 Specifications

General

Channels	5.1
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
FM/AM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	100 dB
Total Harmonic Distortion	0.9%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Audio D/A Converter	192kHz/24-bit
Surround Sound Effects	Yes
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	14
Tuner Bands	FM/AM
Preset Station Qty	40
Frequency Response	10 Hz - 100 kHz
Power Output	100 W per channel
Built-in Decoders	Dolby Digital, DTS
Connector Type	Headphones, Composite video/audio input/output
Video Inputs/Outputs	composite video / audio input, composite video / audio output, HDMI input, HDMI output
Audio Inputs/Outputs	2 Optical digital inputs, 1 Coaxial digital input
