Yealink CP860 User Manual

User Guide for the CP860 HD IP Conference Phone
54
2. Customize specific features for these keys.
3. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
Label is configurable only when customizing Softkeys (1-4).
4. Click Confirm to accept the change.
You can click Reset To Default to reset custom settings to defaults.
Note
Programable key features are explained in the following subchapters in detail:
 Prefix
 Local Group
 XML Group
 LDAP
 Forward
 DND
 Phone Lock
 Directory
 Local Favorite
 Speed Dial
 Direct Pickup
 Group Pickup
 XML Browser
 SMS
 New SMS
 Zero Touch
For the features not listed above, refer to Basic Call Features on page 71 and Advanced Phone
Features on page 98. For more information, contact your system administrator.
You also can assign predefined functionalities to soft keys via phone user interface.

Yealink CP860 Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.729ab, iLBC
Handset type	-
Product type	IP Phone
Product color	Black
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Networking standards	IEEE 802.1x, IEEE 802.3af
Supported network protocols	IPv4/IPv6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Number of handles included	- pc(s)
Storage temperature (T-T)	10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	260 mm
Width	320 mm
Height	52 mm
