Yealink CP920 User Manual

User Guide for the CP920 HD IP Conference Phone
60
2. Customize specific features for these keys.
3. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
Label is configurable only when customizing Softkeys (1-4).
4. Click Confirm to accept the change.
You can click Reset To Default to reset custom settings to defaults.
Note
Programable key features are explained in the following subchapters in detail:
 Prefix
 Local Group
 XML Group
 Forward
 DND
 Phone Lock
 Directory
 Local Favorite
 Speed Dial
 Direct Pickup
 Group Pickup
 XML Browser
 Zero Touch
For the features not listed above, refer to Basic Call Features on page 75 and Advanced Phone
Features on page 104. For more information, contact your system administrator.
Prefix
You can use this key feature to add a specified prefix number before the dialed number.
Dependencies: Type (Prefix)
You also can assign predefined functionalities to soft keys via phone user interface.

Yealink CP920 Specifications

General

Control type	Buttons
Display type	LCD
Product type	IP conference phone
Voice codecs	CNG, G.722, G.722.1C, G.723, G.726, OPUS, VAD, iLBC
Certification	CE
Product color	Stainless steel
Built-in display	Yes
Display diagonal	3.1 \
Display resolution	248 x 120 pixels
Phonebook capacity	1000 entries
Security algorithms	HTTPS
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Microphone direction type	Omnidirectional
AC input voltage	100 - 240 V
USB version	2.0
Storage temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	298 mm
Width	307.8 mm
Height	66.9 mm
Package depth	364 mm
Package width	336 mm
Package height	112 mm
