Yealink SIP-T46S User Manual

User Guide for T4 Series IP Phones
94
5. (Optional.) Enter the destination number you want to transfer the call to in the Value field.
6. Press Save.
Note
Configuring a Call Park Key
You can park a call directly by pressing the call park key during a call.
Procedure:
1. Navigate to Menu->Features->DSS Keys, and then select a desired line key.
2. Select Key Event from the Type field.
3. Select Call Park from Key Type field.
4. (Optional.) Select the desired line from the Account ID field.
Check with your system administrator if it is necessary.
5. (Optional.) Enter the string that will display on the LCD screen in the Label field.
6. (Optional.) Enter the park destination number or call park code you want to park the call to
in the Value field.
7. Press Save.
Note
Configuring a Park Retrieve Key
You can retrieve a parked call directly by pressing the park retrieve key when the phone is idle.
Procedure:
1. Navigate to Menu->Features->DSS Keys, and then select a desired line key.
2. Select Retrieve Park from the Type field.
3. (Optional.) Select a desired line from the Account ID field.
Check with your system administrator if it is necessary.
4. (Optional.) Enter the string that will display on the LCD screen in the Label field.
5. (Optional.) Enter the parked call destination number or retrieve code in the Value field.
6. Press Save.
Note
If the Value field is left blank, the Call Park key performs the same as the Park soft key during a
call.
If the Value field is left blank, the Park Retrieve key performs the same as the Retrieve key on
the dialing screen.
If the Value field is left blank, the Transfer key performs the same as Transfer (Trans) soft key
during a call.
Downloaded from ManualsNet.com search engine

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
