COMPONENT LOCATIONS
FIG. 11 - COMPONENT LOCATIONS
LD10477
CHILLER & VSD
ELECTRICAL PANEL FANS
CONDENSOR
COIL
COMPRESSOR
FILTER
DRIER
OIL
SEPARATORS
GLYCOL
PUMP
KEYPAD/DISPLAY
PANEL
DOOR
6
