140
JOHNSON CONTROLS
FORM 201.21-NM1 (616)
FIG. 16 - VSD LOGIC BOARD
LD10590
COMPONENT LOCATIONS (CON'T)
TECHNICAL DATA
MADE IN THE USA
YORK
R86
(COMPR 4
Over Load Adjust)
R42
(COMPR 3
Over Load Adjust)
R64
(COMPR 2
Over Load Adjust)
R19
(COMPR 1
Over Load Adjust)
