109JOHNSON CONTROLS
FORM NO.: 6U6K-B01E-NB-EN
SECTION 8 – WIRE CONTROLLER OPERATION
Don’t touch the screen with sharp points or edges
which may damage the controller. Don’t twist or pull
the wires of the controller. Don’t wipe the controller
with benzene, diluent or chemical cloth. Otherwise
discoloration or mechanical failure may occur. To remove dirt,
dip the cloth in the water with a neutral detergent and wring
the water before cleaning. Wipe dry the controller with dry
cloth. Do not e xert excessive force on the display or connection
in order to avoid changes in hue.
INTERFACE
INTRODUCTION
The touch screen wire controller is optional for remote controls
of YMAA/YMPA units. The functions of parameter setting,
operating status viewing and fault recording are available.
Instead of describing the information above, the wire controller
utilizes graphic icons in user interface.
Area 1: Date and time display;
Area 2: Timer display;
Area 3: Temperature display (include the set point and actual controlled water temperature);
Area 4: Serial number display;
Area 5: Operating mode setting;
Area 6: Running status display;
Area 7: Touch-keys.
The meanings of the icons are listed in Table 30.
SECTION 8 – WIRE CONTROLLER OPERATION
