SECTION 5 – TECHNICAL DATA

TABLE 11 - YMAA ELECTRICAL DATA (WITHOUT HYDRO KIT)

TABLE 12 - YMPA ELECTRICAL DATA (WITHOUT HYDRO KIT)

TABLE 13 - YMAA ELECTRICAL DATA (WITH HYDRO KIT)

YMAA 0045PE 0065PE 0080PE 0100PE 0130PE

Nominal Voltage/Voltage Limits 400V-3PH-50Hz/360V-440V

Nominal Current at 400V (A) 25.7 36.2 40.6 55.0 70.6

Max Current at 400V (A) 35.1 38.3 60.9 71.7 85.2

Max Current at 360V (A) 40.9 45.2 68.1 82.1 98.9

Unit Short Circuit Current Withstand (kA) 5 5 5 5 5

90.4 108.4 163.4 198.8 212.1

YMPA 0045PE 0065PE 0080PE 0100PE 0130PE

400V-3PH-50Hz/360V-440V

Nominal Current at 25.7 34.5 43.7 56.4 74.2

35.1 38.3 60.9 71.7 85.2

40.9 45.2 68.1 82.1 98.9

Unit Short Circuit Current 5 5 5 5 5

90.4 108.4 163.4 198.8 212.1

YMAA 0045PE 0065PE 0080PE 0100PE 0130PE

400V-3PH-50Hz/360V-440V

Nominal Current at 29.3 39.8 45.3 59.7 75.3

38.7 41.9 65.6 76.4 89.9

44.5 48.8 72.8 86.8 103.6

Unit Short Circuit Current 5 5 5 5 5

90.4 108.4 163.4 198.8 212.1

TABLE 14 - YMPA ELECTRICAL DATA (WITH HYDRO KIT)

YMPA 0045PE 0065PE 0080PE 0100PE 0130PE

400V-3PH-50Hz/360V-440V

Nominal Current at 29.3 38.1 48.4 61.1 78.9

38.7 41.9 65.6 76.4 89.9

44.5 48.8 72.8 86.8 103.6

Unit Short Circuit Current 5 5 5 5 5

90.4 108.4 163.4 198.8 212.1

TABLE 15 - YMAA ELECTRICAL DATA (WITHOUT HYDRO KIT)

YMAA 0160PE 0200PE 0230PE 0260PE

400V-3PH-50Hz/360V-440V

Nominal Current at 88.5 103.1 124.7 139.1

119.5 133.1 166.4 179.9

136.8 153.7 190.6 207.4

Unit Short Circuit Current 5 5 5 5

247.9 261.2 294.3 307.6
