Zebra TC52 User Manual

Accessories
171
Figure 156 Rugged Charge/USB Cable to Host Computer
Charging the Device
To charge the device using the Rugged Charge/USB Cable:
1. Connect the Rugged Charge/USB Cable to the device.
2. Connect the USB connector of the power supply.
NOTE: See Power Supply on page 177 for information on setting up the power supply.
By default, the device includes an interface connector. If the interface connector is removed for USB Type C cable
connectivity, then it must be replaced before charging or receiving an Ethernet IP address if placed in a cradle.
3. Plug to power supply into an power outlet.
Figure 157 Charging Using the Rugged Charge/USB Cable
Disconnecting the Rugged Charge/USB Cable
To disconnect the Rugged Charge/USB Cable from the device:

Zebra TC52 Specifications

General

RFID reader	-
Scanner type	2D
Product color	Black
Phone function	Yes
Display diagonal	5 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
USB 2.0 ports quantity	1
Flash memory	32 GB
Internal memory	4 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	4150 mAh
Number of cores	8
Processor model	660
Processor family	Snapdragon
Processor frequency	2.2 GHz
Processor manufacturer	Qualcomm
GPS (satellite)	No
Operating system installed	Android
Bluetooth version	5.0
Rear camera aperture number	2.2
Front camera aperture number	2
Rear camera resolution (numeric)	13 MP
Front camera resolution (numeric)	5 MP

Weight and Dimensions

Depth	18.6 mm
Width	75.5 mm
Height	155 mm
Weight	249 g
