ZXR105250SeriesCommandReference
CommandMode
Allcongurationmodes
Syntax
showvlanprotocol-mapping
Example
ThefollowingexampleshowsprotocolVLANcongurations:
zte(cfg)#showvlanprotocol-mapping
SessionIdVlanIdEncapTypeProtocolType
------------------------------------
2100ethernet20x1234
4.6VoiceVLANConguration
4.6.1setvlanvoice-vlan
Purpose
ThiscommandsetsthevoiceVLANfunctiononaport.
CommandMode
Globalcongurationmode
Syntax
setvlanvoice-vlanport<1-52>ingress-vlan<vlanlist>voice-vlan<1-4094>
ParameterDescription
ParameterDescription
<1-52>
Portnumber.Differentdeviceshavedifferentportnumberranges.
Inthesyntax,the5250-52TCdeviceisusedasanexample.
<vlanlist>UserVLANidlist.
<1-4094>VoiceVLANid.
Guidelines
Portcongurationscannotbemodiedorcovered.Ifmodicationsarerequired,clearthe
originalcongurationsrstandthenre-conguretheports.
4-86
SJ-20131111172707-003|2013-11-27(R1.0)ZTEProprietaryandCondential

Zte ZXR10 5250-28SM Specifications

General

Model	ZXR10 5250-28SM
Switching Capacity	128 Gbps
Forwarding performance	95.2 Mpps
Forwarding Rate	95.2 Mpps
MAC Address Table	16K
Jumbo Frame Support	9K Bytes
Storage Temperature	-40°C to 70°C
Power Supply	AC 100-240V, 50/60Hz
Dimensions (W x D x H)	440mm x 260mm x 44mm
Weight	3.5 kg
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Ports	24x 10/100/1000BASE-T, 4x 100/1000BASE-X SFP
