ZXR105250SeriesCommandReference
ParameterDescription
dscp<0-63>
ThisruleisonlyvalidformessageswiththespeciedDSCP
value.Ignorethisruleforothermessages.TherangeofDSCP
valueis0to63.
fragment
Thisruleisonlyvalidforfragmentmessages.Fornon-fragment
messages,thisruleisignored.
cos<0-7>
Thisruleisonlyvalidforthecos-speciedmessage.Ignorethis
ruleforothermessages.Therangeofcosis0to7.
<vlan-id>
ThisruleisonlyvalidformessageswiththespeciedVLANID.
Ignorethisruleforothermessages.TheruleofVLANIDis1
to4094.
<vlan-mask>OptionalVLANmask.Thedefaultvalueis0xfff.
<source-mac>SourceMACaddressofthetransmittedpacket.
<smac-mask>SourceMACmask.
any(third)
TheanykeywordisusedastheabbreviationofthesourceMAC
address00.00.00.00.00.00andthemask00.00.00.00.00.00.
<dest-mac>DestinationMACaddressofthetransmittedpacket
<dmac-mask>DestinationMACaddressofthetransmittedpacket
any(fourth)
Theanykeywordisusedastheabbreviationofthedestination
MACaddress00.00.00.00.00.00andthemask00.00.00.00.00.00.
Guidelines
TheTCPrulecanmatchsource-speciedIPs,anysourceIPs,destination-specied
IPs,anydestinationIPs,DSCPelds,IPfragmentelds,coselds,VLANelds,
source-speciedMACs,anysourceMACs,destination-speciedMACs,andany
destinationMACs.
4.13.29ingress-aclhybridruletype-udp
Purpose
ThiscommandsetstherulethatthehybridingressACLmatchestheIPv4-UDPpacket.
CommandMode
HybridingressACLcongurationmode
Syntax
rule<1-500>{permit|deny}udp{<source-ipaddr><sip-mask>|any}[source-port<0-65535><s
port-mask>]{<destination-ipaddr><dip-mask>|any}[dest-port<0-65535><dport-mask>][dscp
4-238
SJ-20131111172707-003|2013-11-27(R1.0)ZTEProprietaryandCondential

Zte ZXR10 5250-28SM Specifications

General

Model	ZXR10 5250-28SM
Switching Capacity	128 Gbps
Forwarding performance	95.2 Mpps
Forwarding Rate	95.2 Mpps
MAC Address Table	16K
Jumbo Frame Support	9K Bytes
Storage Temperature	-40°C to 70°C
Power Supply	AC 100-240V, 50/60Hz
Dimensions (W x D x H)	440mm x 260mm x 44mm
Weight	3.5 kg
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Ports	24x 10/100/1000BASE-T, 4x 100/1000BASE-X SFP
