ZXR105250SeriesCommandReference
ParameterDescription
<0-7>
ImplementsthenewUPvalueaftermodication.Thevalueis0
forprole0...7forprole7.Thevalueis0forproles8to127.
traffic-classModiesTCs.
<0-7>
TCsthatprolescorrespondto:
lBydefault,proles0to7correspondtoTCs0to7onebyone.
lProles8to15correspondtoTC0.
lProles16to23correspondtoTC1.
lProles24to31correspondtoTC2.
lProles32to39correspondtoTC3.
lProles40to47correspondtoTC4.
lProles48to55correspondtoTC5.
lProles56to63correspondtoTC6.
lProles64to71correspondtoTC7.
lProles72to127correspondtoTC0.
Guidelines
Thedrop-priority,dscp-priority,user-priority,andtrafc-classparameterscanbecongured
separately.
Example
ThefollowingexamplesetstheQoSprole100dropprioritytoyellow,DSCPpriorityto5,
userpriorityto2,andTCto2:
zte(cfg)#setqospriority-mappingqos100drop-priorityyellow
zte(cfg)#setqospriority-mappingqos100dscp-priority5
zte(cfg)#setqospriority-mappingqos100user-priority2
zte(cfg)#setqospriority-mappingqos100traffic-class2
zte(cfg)#showqospriority-mappingqos-profile100
QoSMappingProfileTable:
Flags:QosIndex-PriorityMappingProfile
TrafficClass-LocalTrafficClass,DropPri-LocalDropPriority
DSCPNew-NewUserPriorityValueIfRemarkDSCPPriorityEnable
UsrPriNew-NewUserPriorityValueIfRemarkUserPriorityEnable
QosIndexTrafficClassDropPriDSCPNewUsrPriNew
-------------------------------------------------------------------------------
Profile-100COS-2YELLOW5UP-2
4.14.8setqospriority-mappingqos-profiledefault
Purpose
Thiscommandsets128QoSprolestorecoverdefaultvalues.
4-306
SJ-20131111172707-003|2013-11-27(R1.0)ZTEProprietaryandCondential

Zte ZXR10 5250-28SM Specifications

General

Model	ZXR10 5250-28SM
Switching Capacity	128 Gbps
Forwarding performance	95.2 Mpps
Forwarding Rate	95.2 Mpps
MAC Address Table	16K
Jumbo Frame Support	9K Bytes
Storage Temperature	-40°C to 70°C
Power Supply	AC 100-240V, 50/60Hz
Dimensions (W x D x H)	440mm x 260mm x 44mm
Weight	3.5 kg
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Ports	24x 10/100/1000BASE-T, 4x 100/1000BASE-X SFP
