Chapter4ServiceConguration

ParameterDescription

<dip-mask>

Destinationmaskusedfordestination.Itisa32-bitIPaddress

expressedindotteddecimalnotation.

any(second)

Theanykeywordisusedastheabbreviationofthedestination

0.0.0.0andthedestinationmask0.0.0.0

dest-port<0-65535>

TCPdestinationportnumberofthetransmittedpacket

Theparametersofdest-portcanresolvethesomeknownport

numbers.Alsotheportnumberandmaskcanbedirectlyinputted.

<dport-mask>Destinationportmask.

dscp<0-63>

ThisruleisonlyvalidforthemessagewiththespeciedDSCP

value.Ignorethisruleforothermessages.TherangeofDSCP

valueis0to63.

fragment

Thisruleisonlyvalidforfragmentmessages.Fornon-fragment

messages,thisruleisignored.

cos<0-7>

Thisruleisonlyvalidforthecos-speciedmessage.Ignorethis

ruleforothermessages.Therangeofcosis0to7.

<vlan-id>

ThisruleisonlyvalidformessageswiththespeciedVLANID.

Ignorethisruleforothermessages.TheruleofVLANIDis1

to4094.

<vlan-mask>OptionalVLANmask.Thedefaultvalueis0xfff.

<source-mac>SourceMACaddressofthetransmittedpacket.

<smac-mask>SourceMACmask.

any(third)

TheanykeywordisusedastheabbreviationofsourceMAC

address00.00.00.00.00.00andmask00.00.00.00.00.00.

<dest-mac>DestinationMACaddressofthetransmittedpacket.

<dmac-mask>DestinationMACaddressofthetransmittedpacket.

any(fourth)

Theanykeywordisusedastheabbreviationofthedestination

MACaddress00.00.00.00.00.00andmask00.00.00.00.00.00

Guidelines

TheTCPrulecanmatchsource-speciedIPs,anysourceIPs,destination-specied

IPs,anydestinationIPs,DSCPelds,IPfragmentelds,coselds,VLANelds,

source-speciedMACs,anysourceMACs,destination-speciedMACs,andany

destinationMACs.

4.13.73egress-aclhybridruletype-udp

Purpose

ThiscommandsetstherulethatthehybridegressACLmatchesIPv4-UDPpackets.

4-287

SJ-20131111172707-003|2013-11-27(R1.0)ZTEProprietaryandCondential
