144 Parameters
Fault always Drive trips on 7510 FBA A communication. This occurs even
though no control is expected from the fieldbus.
4
Warning Drive generates an A7C1 FBA A communication warning.
This occurs even though no control is expected from the
fieldbus.
WARNING! Make sure that it is safe to continue
operation in case of a communication break.
5
50.03 FBA A comm loss t
out
Defines the time delay before the action defined by parameter
50.02 FBA A comm loss func is taken. Time count starts when
the communication link fails to update the message.
0.3 s
0.3…6553.5 s Time delay. 1 = 1 s
50.04 FBA A ref1 type Selects the type and scaling of reference 1 received from
fieldbus adapter A. The scaling of the reference is defined by
parameters 46.01…46.04, depending on which reference
type is selected by this parameter.
Note: Applicable only when 79.40 MPPT reference is
disabled. If parameter MPPT reference is enabled, then the
parameter should be set to it’s default value.
Speed or
frequency
Speed or frequency Type and scaling is chosen automatically according to the
currently active operation mode as follows:
0
Transparent No scaling is applied. 1
General Generic reference without a specific unit. 2
Torque The scaling is defined by parameter 46.03 Tor qu e sc a l ing .3
Speed The scaling is defined by parameter 46.01 Speed scaling.4
Frequency The scaling is defined by parameter 46.02 Frequency scaling.5
50.05 FBA A ref2 type Not applicable
50.06 FBA A SW sel Selects the source of the Status word to be sent to the
fieldbus network through fieldbus adapter A.
Auto
Auto Source of the Status word is chosen automatically. 0
Transparent mode The source selected by parameter 50.09 FBA A SW
transparent source is transmitted as the Status word to the
fieldbus network through fieldbus adapter A.
1
50.07 FBA A actual 1 type Selects the type and scaling of actual value 1 transmitted to
the fieldbus network through fieldbus adapter A. The scaling
of the value is defined by parameters 99.09, 99.08, 46.03 and
46.04 depending on which actual value type is selected by
this parameter.
Speed or
frequency
Speed or frequency Type and scaling is chosen automatically according to the
currently active operation mode as follows.
0
Transparent No scaling is applied. 1
General Generic reference without a specific unit. 2
No. Name/Value Description Def/FbEq16
Operation mode Reference 1 type
Speed control Speed
Frequency control Frequency
Motor control mode
(see par. 99.04)
Actual 1 type
Speed control Speed
Frequency control Frequency
ACQ80 FW.book Page 144 Thursday, February 14, 2019 11:33 AM
