INTRODUCTION
SPECIFICATIONS
1 - 7
SPECIFICATIONS
Table 1-3 provides performance specifications of the Type AV1
and Type AV2 positioners. Tables 1-4 and 1-5 provide perfor-
mance specifications for the position transmitters.
Manifold (includes filters)/Gage Block
0 No manifold
1 Manifold with equalizing valve, filters and gage ports (required for dou-
ble acting actuators with manual override)
2 Manifold with equalizing valve inoperable (includes filters and gage
ports)
3
3 Gage block (gage port only)
1
Position Transmitter
0 None (must be 0 for Types AV15, AV16 and AV27)
1 Potentiometric resistive output
2 4 to 20-mA output
Drive Shaft
0 Standard with feedback arm for linear motion
1 0.500-in. square end
2 0.342-in. square end for older DeZurik actuators
3 0.250 in. across flats (UP1 and UP2 after August, 1995)
4 0.375 in. square for DeZurik PowerRac
®
actuators
5 0.156 in. across flats for NAMUR rotary actuators
Other Options
0 Standard (no other options)
N NEMA 4X enclosure rating (when installed per drawing C258567)
P Performance Series — high pneumatic gain for large actuators
NOTES:
1. High temperature Type AV1 positioners are only available without manifolds or position transmitters; however, gage blocks are permitted.
2. Explosionproof Type AV2 positioners are not available with position transmitters or manifolds
3. No longer available as of October 2003..
Table 1-2. Nomenclature (continued)
Position123456789
Type A V
_______
Characterizable Positioners
Prev
Table 1-3. Type AV1/2 Positioner Specifications
1
Property Characteristic/Value
Input range
AV11 and AV15 20.7 to 103.4 kPa (3.0 to 15.0 psig)
AV12 and AV16 20.7 to 186.2 kPa (3.0 to 27.0 psig)
AV23 and AV27 4 to 20 mA
Input impedance (Type AV2 only)
Nominal 215 Ω at 22°C (72°F)
