INTRODUCTION
SPECIFICATIONS
1 - 13
Table 1-8. Rotary Actuator Retrofit Mounting Kits
Kit Number Drive Nomenclature Retrofit Mounting Kit
5400309_1 UP1, UP2 Type AP positioner to
Type AV positioner
258493_1 UP3, UP4
258494_1 UP5, UP6
258527_1 AC0404
258528_1 AC0608
258529_1 AC0816
258530_2 AC1016
258527_1 AC0404 ABB part number pilot
valve positioner to Type
AV positioner
258528_1 AC0608
258529_1 AC0816
258530_1 AC1016
Table 1-9. Speed Control Orifices
1
Part Number
Size
mm in.
5327327_1 1.02 0.04
5327327_2 Blank (drill to suit) Blank (drill to suit)
NOTE:
1. Speed control can also be obtained by internal positioner adjustment. Refer to PILOT VALVE
STROKE ADJUSTMENT in Section 4.
Table 1-10. Pressure Gages
Part Number Legend
Range
kPa psig
5326605_4 Instrument 0 to 200 0 to 30
5326605_5 Supply
1
0 to 1,000 0 to 160
5326605_6 Output 0 to 1,000 0 to 160
NOTE:
1. The optional manifold provides gage ports, one for instrument (internal input signal), and two out-
put gages. A supply gage can be installed in the supply line (piping by customer).
Table 1-11. Supply Air Regulators with Gages
Part Number
Max. Outlet
Pressure (psig)
Max. Inlet
Pressure (psig)
Inlet/Outlet
Connections
1951029_5 125 250 ¼ NPT
Table 1-12. Supply Air Filters
1
Part Number
Max. Inlet
Pressure
(psig)
Max. Temperature Inlet/Outlet
Connection
Size
°C °F
5328563_2 250 121.0 125.0 ¼ NPT
NOTE:
1. In-line coalescing filter for removal of solid and liquid contaminants in compressed air. Filter
comes with universal mounting bracket and grade 6 filter that is 99.97% efficient at 0.3 micron. Part
number 5328563_2 has a zinc bowl.
