INTRODUCTION
REFERENCE DOCUMENTS
1 - 6
The section arrangement of this instruction is sequential. After ini-
tial start-up and calibration, store this instruction in a safe place for
future reference.
REFERENCE DOCUMENTS
NOMENCLATURE
Table 1-1. Reference Documents
Number Title
ANSI/NFPA 70 National Electrical Code
CEC Canadian Electrical Code
D-AAP-UP Universal Pneumatic Rotary Actuator, Type UP (specification)
D-APE-AV1234 Characterizable Positioners, Type AV1, AV2, AV3 & AV4 (specification)
CSA c22.1 Process Control Equipment
I-E96-500 Site Planning and Preparation
I-P81-20 Universal Pneumatic Rotary Actuator, Type UP (instruction)
ANSI/ISA-7.0.01-1996 Quality Standards for Instrument Air
ISA S75.13-1989 Method of Evaluating the Performance of Positioners with Analog Input Signals and
Pneumatic Output (Instrument Society of America)
P-P88-001 Product Application Guide, Installing a Type AV Positioner in a Hazardous Location
Table 1-2. Nomenclature
Position123456789
Type A V
_______
Characterizable Positioners
1
Characterizable Pneumatic Positioner
2
Characterizable 4 to 20-mA Input Positioner (actuator moves to 0%
or 100% upon loss of signal)
Input Signal
1 20.7 to 103.4 kPa (3.0 to 15.0 psig) (Type AV1)
2 20.7 to 186.2 kPa (3.0 to 27.0 psig) (Type AV1)
3 4 to 20 mA (standard intrinsically safe Type AV2)
5 20.7 to 103.4 kPa (3.0 to 15.0 psig), high temperature applications
(Type AV1)
1
6 20.7 to 186.2 kPa (3.0 to 27.0 psig), high temperature applications
(Type AV1)
1
7 4 to 20 mA with explosionproof I/P converter (NEMA 7) (Type AV2)
2
Stroke/Rotary Motion (cam selection)
1 12.7 to 50.8 mm (0.5 to 2.0 in.) or 45° rotary motion
2 25.4 to 101.6 mm (1.0 to 4.0 in.) or 90° rotary motion
