ABB AV2 User Manual

INSTALLATION
MOUNTING TYPE AV POSITIONERS
3 - 5
the kit. If using the positioner with a rotary actuator, the positioner can be
directly connected to the actuator, as shown in Figure 3-6.
NOTE: If the actuator is equipped with a Type AV positioner as
ordered, verify that all the connections are secure and make any
adjustments as required.
Figure 3-4. Drive Shaft Variations
Figure 3-5. Mounting Using Linkage (Typical)
MOUNTING PLANE
T00927A
TYPE AV?????3?
0.250-IN. FLATS
6.35
0.250
7.21
0.284
5.84
0.230
TYPE AV?????4?
0.375-IN. SQUARE END
(FOR DEZURIK POWER-RAC
ACTUATORS)
8.13
0.320
17.3
0.680
9.53
0.375
TYPE AV?????2?
0.342-IN. SQUARE END
17.3
0.680
17.1
0.675
8.69
0.342
TYPE AV?????1?
0.5-IN. SQUARE END
20.8
0.820
12.7
0.500
DIMENSIONS
MILLIMETERS
INCHES
4.06
.160
4.06
.160
24.64
.970
TYPE AV?????5?
0.156-IN. FLATS
6.35
0.250
TYPE AV
POSITIONER
ELASTIC
STOP NUT
STEM CLAMP,
CLAMP PLATE
FRONT VIEW SIDE VIEW
T00802A
MOUNTING BRACKET
ADJUSTABLE
CONNECTING LINK
ADJUSTABLE STUD
PAN HEAD MACHINE SCREW
NOTE: DRIVE ARM SHOULD BE
PERPENDICULAR WITH THE
AC T UATOR AT M ID STRO KE .
G2
G1
