REPAIR AND REPLACEMENT
PILOT VALVE STROKE ADJUSTMENT
8 - 9
Figure 8-4. Stroke Adjustment Screws
LOWER ADJUSTMENT
SCREW
HINGE SPRING
SIGNAL
DIAPHRAGM
TOP ADJUSTMENT SCREW
RANGE SPRING
ALLEN WRENCH
ACCESS
T00778A
