ADDITIONAL SPARE PARTS
9 - 3
ADDITIONAL SPARE PARTS
Table 9-7. Pilot Valve Assembly Kit No. 258488_3
(for Types AV11___P, AV12___P and AV2___P)
Item Part No. Qty Description
3 5400259_1 1 Valve stem
4 5400260_2 1 Valve body
5 5400261_1 1 Valve clip
35 1951398_12 3 O-rings
— 19984_1 1 O-ring lubricant
Table 9-8. Pilot Valve Assembly Kit No. 258488_4
(for Types AV15_0/3__P and AV16_0/3__P)
Item Part No. Qty Description
3 5400259_1 1 Valve stem
4 5400260_2 1 Valve body
5 5400261_1 1 Valve clip
35 1951779_010 3 O-rings
— 19984_1 1 O-ring lubricant
Table 9-9. Cam
(select appropriate cam type)
Part No. Qty Description
5400281_1 1 Forward acting full rise cam, 90° rotation
5400281_2 1 Reverse acting full rise cam, 90° rotation
5400289_1 1 Forward acting half rise cam, 45° rotation
5400289_2 1 Reverse acting half rise cam, 45° rotation
Table 9-10. AV2 I/P Assembly Kit No. 258651_1
Part No. Qty Application Description
258651_1 1 AV2 I/P converter kit
Table 9-11. Gain Hinge Springs
1
Item Part No. Qty
Thickness
Gain
mm in.
7 5400264_1
2
1 0.25 0.010 High
5400264_2 1 0.76 0.030 Medium
NOTES:
1. For small actuators, it may be necessary to combine both gain hinge springs.
2. The high gain hinge spring comes installed from the factory.
