Table 9-28. Shaft Position Transmitter Parts Reference for Type AV1 Positioners (Fig. 9-3)
Type
Item (Part Number) Item (Quantity)
21
27, 50, 59, 61, 75,
83, 84, 86, 87, 89
31 58 77, 78 90
AV1
___0__ Omit Omit — Omit Omit Omit
AV1
___1__ 6639542_213+16Omit2
AV1
___2__ 6639542_113 +1812
Table 9-29. Drive Shaft Parts Reference
for Type AV1 Positioners (Fig. 9-3)
Type
Item (Part Number) Item (Quantity)
14 63 34
AV1
_1__0_ 5400287_1 5327445_21
AV1
_2__0_ 5400287_1 5327445_11
AV1
____1_ 5400278_1 Omit Omit
AV1
____2_ 5400287_2 Omit Omit
AV1
____3_ 5400287_3 Omit Omit
AV1
____4_ 5400287_4 Omit Omit
AV1
____5_ 5400287_5 Omit Omit
Table 9-30. Type AV2 Positioner Parts List for Figure 9-4
Item Part No. Description Item Part No. Description
1 5400253_3 Housing 54 NTCHA07000
2
Diaphragm support scr washer
2 5400258
_1 Cover assembly 55 NTGHA10000 Cam washer
3 5400259
_1 Valve stem 56 NTJHA09030 Span adjustment washer
4 Refer to Table 9-31 Valve body 57 Form MP432-889 Label, indicator
5 5400261
_1 Valve clip 58 197893_1 Thread forming screw (8 req)
6 5400263
_1 Beam assembly 59 6639559_1 Termination assembly
7 5400264
_1 Hinge 61 197893_1 Label, CSA/FM
8 258544
_1 Cam follower arm assembly 62 1963318__ Nameplate, universal
9 5400271
_1 Spring arm 63 Refer to Table 9-31 Drive arm
1
10 5400272_1 Pivot 64 5311428_207 Manifold O-ring
1
11 5400273_1 Eyebolt 65 NTJHA09030 Manifold washer
1
12 5400275_1 Retainer nut 66 NBAHA16020 Manifold screw
1
13 Refer to Table 9-31 Cam 67 NBAHA16024 Manifold screw
1
14 Refer to Table 9-31 Cam shaft 68 R9025-0046 Tubing (50.8 cm (20.0 in.))
15 5400279
_1 Zero adjustment nut 70 NIDHA09005 Pan head sems screw
16 5400280
_1 Range spring 71 193197_1 Span adjustment bearing
17 Refer to Table 9-32 Manifold assembly 72 1943187
_1 Cable clip
18 193214
_1 Bearing 73 5400288_1 Large diaphragm
19 5400286
_1 Indicator 74 114B094U01 Plug
20 5400288
_1 Small diaphragm 75 1951655_1 Brass fitting (1 req)
21 Refer to Table 9-33 Potentiometer assembly 76 5400989
_2 I/P bracket
22 5400292
_1 Diaphragm spacer 77 5400304_1 I/P support
23 5400293
_1 Diaphragm support 78
24 5400294
_1 Diaphragm ring 79
