SUPPORT SERVICES ADDITIONAL SPARE PARTS 9 - 10
Table 9-26. Input Signal Parts Reference for Type AV1 Positioners (Fig. 9-3)
Type
Item (Part Number)
Item
(Quantity)
2 4 20 23 25 29 35 73 81 82 93 31 94 95
AV11____0 5400258_1 5400260_1 5400288_2 5400293_1 5400295_1 114B095U01 1951398_12 5400288_1 1951755_1 1951755_2 1951631_206 2 Omit Omit
AV11
____N 5400258_1 5400260_1 5400288_2 5400293_1 5400295_1 1943573_1 1951398_12 5400288_1 1951755_1 1951755_2 1951631_206 2 2 1
AV11
____P 5400258_1 5400260_2 5400288_2 5400293_1 5400295_1 114B095U01 1951398_12 5400288_1 1951755_1 1951755_2 1951631_206 2 Omit Omit
AV12
____0 5400258_1 5400260_1 5400288_2 5400293_2 5400295_2 114B095U01 1951398_12 5400288_3 1951755_1 1951755_2 1951631_206 2 Omit Omit
AV12
____N 5400258_1 5400260_1 5400288_2 5400293_2 5400295_2 1943573_1 1951398_12 5400288_3 1951755_1 1951755_2 1951631_206 2 2 1
AV12
____P 5400258_1 5400260_2 5400288_2 5400293_2 5400295_2 114B095U01 1951398_12 5400288_3 1951755_1 1951755_2 1951631_206 2 Omit Omit
AV15
____0 5400258_3 5400260_1 5400288_5 5400293_1 5400295_1 1945803_1 1951779_10 5400288_4 1951755_3 Omit 1951799_206 Omit 2 Omit
AV15
____N 5400258_3 5400260_1 5400288_5 5400293_1 5400295_1 1943573_1 1951779_10 5400288_4 1951755_3 Omit 1951799_206 Omit 2 1
AV15
____P 5400258_3 5400260_2 5400288_5 5400293_1 5400295_1 1945803_1 1951779_10 5400288_4 1951755_3 Omit 1951799_206 Omit 2 Omit
AV16
____0 5400258_3 5400260_1 5400288_5 5400293_2 5400295_2 1945803_1 1951779_10 5400288_6 1951755_3 Omit 1951799_206 Omit 2 Omit
AV16
____N 5400258_3 5400260_1 5400288_5 5400293_2 5400295_2 1943573_1 1951779_10 5400288_6 1951755_3 Omit 1951799_206 Omit 2 1
AV16
____P 5400258_3 5400260_2 5400288_5 5400293_2 5400295_2 1945803_1 1951779_10 5400288_6 1951755_3 Omit 1951799_206 Omit 2 Omit
Table 9-27. Cam Selection and Manifold/Gage Block Parts Reference for Type AV1 Positioners (Fig. 9-3)
Type
Item (Part Number) Item (Quantity)
13 17 64 65 66 67 91 92
AV1_1____ 5400289_1,2— — —————
AV1
_ 2____ 5400281_1,2— — —————
AV11/2
_0___ — Omit Omit Omit Omit Omit Omit Omit
AV11/2
_1___ — 5400282_1 5311428_207 (4 req) 4 2 2 Omit Omit
AV11/2
_2___ — 5400282_2 5311428_207 (4 req) 4 2 2 Omit Omit
AV11/2
_3___ — 5400318_1 5311428_207 (4 req) 3 3 Omit 3 3
AV15/6
_ 00__ — Omit Omit Omit Omit Omit Omit Omit
AV15/6
_30__ — 5400318_1 5311428_207 (4 req) 3 3 Omit 3 3
