ABB CL-LSR 12AC2 Series User Manual

Logic relay
12
1SVC 440 795 M0100
Overview
Figure 1: CL basic units and expansions
Legend for figure 1:
a CL-LSR/CL-LST logic relays
b CL-LER, CL-LET input/output expansion
c CL-LER.2O output expansion
d Coupler unit for CL-LEC.CI000 remote expansion
e CL-LINK CL-LAS.TK011 data plug
f CL-LMR/CL-LMT logic relays
The logic relay is an electronic control relay with logic
functions, timer, counter and time switch functions. It is also
a control and input device rolled into one. With the logic
relay you can create solutions for domestic applications as
well as for tasks in machine and plant construction.
Circuit diagrams are connected up using ladder diagrams,
and each element is entered directly via the CL display.
a
b
b
c
d
e
f
