Timing relays
161
1SVC 440 795 M0100
Examples timing relay
Example: Timing relay, on-delayed
In this example a conveyor starts 10 s after the system is
powered up.
Example: Timing relay, off-delayed
The off-delayed function is used to implement a rundown
time on the conveyor if required.
Example: Timing relay, on- and off-delayed
The on/off-delayed function is used to implement the delay
of both the startup and the disconnection if required.
Circuit diagram display Parameter settings of
timing relay T1
Circuit diagram display Parameter settings of
timing relay T2
Circuit diagram display Parameter settings of
timing relay T3
I5-------TT1
T1-------ÄQ1
T1 X S +
I1 10.000
I2
I6-------TT2
T2-------ÄQ2
T2 â S +
I1 30.000
I2
I6-------TT3
T3-------ÄQ3
T3 Xâ S +
I1 10.000
I2 30.000
