Wiring with the logic relay
176
1SVC 440 795 M0100
Example: Resetting outputs and markers
All outputs and markers that you have used can be reset to
0 with one command.
A rising edge at the coil of Z3 will cause all Q and S outputs
and all M and N markers to be reset.
Basic circuits The values in the logic table have the following meanings
For switching contacts:
• 0 = n/o contact open, n/c contact closed
• 1 = n/o contact closed, n/c contact open
For Q…: relay coils
• 0 = coil not energized
• 1 = coil energized
Negation (contact)
Negation means that the contact opens rather than closes
when it is actuated (NOT circuit).
In the CL circuit diagram, press the ALT button to toggle
contact I1 between n/c and n/o contact.
Table 14: Negation
I8-------ÈZ3
I5-------ÄQ1
I2-M1-T1-SS3
M3uC1----SQ3
M4b
I1-------ÄM1
I7-C2-T1-SN3
T3-A1----SM8
M4-A5----SN8
i1-------ÄQ1
I1 Q1
1 0
0 1
