Wiring with the logic relay
152
1SVC 440 795 M0100
The following conversion rules apply if you are using variable
values such as an analog input:
s time base
Equation: Time setpoint = ( Valuex10) in [ms]
M:S time base
Rule:
Time setpoint = Value divided by 60,
integer result = Number of minutes, remainder is the number
of seconds
h
You can only use analog values as setpoints if the value of
the analog input is stable. Fluctuating analog values
reduce the reproducibility of the time value.
Value, e.g. Analog
input
Time setpoint in [s]
0 00.00
100 01.00
300 03.00
500 05.00
1023 10.23
Value, e.g. Analog
input
Time setpoint in
[M:S]
0 00:00
100 01:40
300 05:00
500 08:20
1023 17:03
