Function blocks
233
1SVC 440 795 M1100
Parameter display and parameter set for the numerical
converter:
In the parameter display of a numerical converter you can
change the mode and the enable of the parameter display.
Numerical converter modes
Number range
NC02 BCD +
>I1
QV>
NC02 Numerical converter function block number 02
BCD Convert BCD code to decimal value mode
+ Appears in the parameter display
>I1 Input value
QV> Output value
Parameter Operating mode
BCD Convert of BCD coded values to decimal values
BIN Convert decimal value to BCD coded values
Value Number system
–161061273 to +161061273 BCD
–9999999 to +9999999
Decimal
BCD code Decimal value
0001 1
0010
2
0011
3
0100
4
0101
5
0110
6
0111
7
1000
8
1001
9
1010 to 1111
Not permissible
10000
10
10001
11
